Forged Steel F316 2” 150LB RF FLANGE Gate Valve
| Valve Size | 1/4 “–2”, DN10–DN50 |
| Pressure Class | 150LB–2500LB, PN16–PN420 |
| Materials | Carbon Steel: A105, LF2, Stainless Steel: F304, F304L, F316, F316L, Duplex: F51, F55, Alloy: F1, F5, F5A, F9, F11, F22 |
| Design and Manufacturing Standards | API602, ASME 16.34, BS 5352, BS 6364 |
| Face to Face Standards | API 602 |
| Flange Dimension Standards | SW Socket welding ends according to ASME B16.11, BW butt end by ASME B16.25, NPT threaded connectors according to ASME B1.20.1 |
| Pressure Test Standards | API 598 |
| Fire Safety Test Standards | – |
| Quality/Product Certifications | ISO9001, ISO14001, ISO18001 |
| Fugitive Emissions | ISO 15848-1, API 622 |
| Valve Operator Options | Hand wheel, Worm Gear, Electric actuator, Pneumatic actuator, Hydraulic Actuator |
| Shutoff Class | API 598 (Zero Leakage), API 6D |
| Bore | Full Bore, Reduced Bore |
| Process Connection Types | SW, NPT, BW, RF, RTJ |
Product Overview
Designed for use in high-temperature steam and water, this multipurpose gate valve can be used in a wide variety of general-purpose applications including vents, drains and isolation of compressors, condensers, heaters, pumps, water lines, heat exchangers, bypass lines, flash tanks, control valves, etc.
